Folding Door Hardware

Niko Folding Door Track Systems

NIKO industrial folding door track systems comprise a range of track sizes and components that bolt together to facilitate sliding and folding movement for opening and closing doors.

Benefits, Features, and Technical Specification

Features

Niko industrial folding door track is the ideal solution for a large range of applications including:

Folding doors for factories and industrial units
Warehouse folding doors
Folding doors for aircraft hangars
Agricultural folding doors – barns, farms and stable partitions
Commercial folding doors – restaurants, shops, garages, schools, offices etc.

Benefits

Easy to install, extend or move
Free running – requires 1/100 weight to force ratio to move doors
Low maintenance – bearings and track do not need to be oiled
High reliability – certified for 100,000 cycles
Near silent operation
Easy to use
Tapered edge track profile means door hangers always run smooth and do not snag or bind
Compact size – allowing for space utilisation
Track profile designed to reduce build up of dust, dirt and ice
Space effective solutions for sliding doors

Technical Specification

Door weights from 10kg to 500kg
Internal and external applications
Centre folding or end folding variations
Range of brackets for various fixing methods
Range of hangers for all types of doors
Suitable for steel or timber doors
No limit to the opening size

Components Kit

Example layout 1 – folding from one side

Example layout 2 – meeting in the middle

Configuration Options

Bi-Fold / End Folding Sliding Doors (door fixed in corner of the panel)

Doors fold at the end of panels and lay flat when in the open position. This method uses the least amount of space to store the doors and only protrudes from one side of the track.

Harmonica / Centre Folding Sliding Doors (door fixed in middle of the panel)

Doors fold from centre of panels and lay flat when in the open position. This method requires that the first door panel is half the width of all of the subsequent doors. It utilises the space on both sides of the track so that the storage is not all to one side.

Standard components for a folding door track system.

Top track

Suspends the weight of the door

Support brackets

For fixing track to wall or soffit etc.

Leading hanger

Usually the same as the other hangers.

Hangers (also known as trolleys, runners or wheels)

Slide inside top track

Door bracket

Fix to top of door panel and fasten hanger

Floor guide

Fix to bottom of door panel and locates inside guide rail

Floor guide track

Stops swinging motion of door panels

Track End Stops

Stop hangers leaving top track (not shown on drawings)

Important factors & FAQs

How can Folding Door Hardware improve productivity?

Folding Door Hardware help operators complete routine tasks more quickly and consistently. By reducing wasted movement, improving access and creating a more structured workflow, companies can increase throughput while keeping processes simple and reliable.

How do Folding Door Hardware improve safety for operators?

Folding Door Hardware reduce unnecessary manual effort, awkward movement and uncontrolled handling. This helps lower the risk of workplace injuries and gives operators a safer, more predictable way to complete daily tasks.

What business benefits do Folding Door Hardware deliver?

Businesses benefit from improved efficiency, reduced downtime, better use of space and lower risk of injury-related disruption. The result is a more productive workplace with equipment that supports long-term operational performance.

Can Folding Door Hardware reduce manual handling?

Yes. Folding Door Hardware are designed to reduce the need for operators to lift, carry, drag or reposition items manually. This improves ergonomics and allows staff to focus on higher-value work.

Are Folding Door Hardware suitable for retrofit projects?

In many cases, yes. Niko systems can often be incorporated into existing facilities, buildings or work areas, helping companies upgrade safety and productivity without a complete redesign.

Which industries commonly use Folding Door Hardware?

Folding Door Hardware are suitable for sectors including Agricultural, Construction, Aerospace & Defence, Commercial Buildings. They are particularly useful wherever reliability, safety and efficient movement are important.

How can Folding Door Hardware reduce downtime?

By improving reliability and making daily operations easier to manage, Folding Door Hardware help reduce delays caused by inefficient movement, access restrictions or avoidable maintenance issues.

Can Folding Door Hardware improve workplace ergonomics?

Yes. Operators benefit from smoother movement, reduced effort and better control. This can reduce fatigue and support healthier, more sustainable working practices.

How do Folding Door Hardware help companies control costs?

Better workflow, fewer handling delays, lower maintenance disruption and reduced injury risk can all contribute to lower operating costs over the life of the system.

Can Folding Door Hardware be customised?

Niko solutions can be configured around the application, load, environment and workflow requirements. This helps ensure the system supports the way the customer actually works.

What maintenance do Folding Door Hardware require?

Routine inspection and preventative maintenance help maximise reliability and service life. Niko products are designed to deliver dependable performance with sensible maintenance requirements.

How do Folding Door Hardware support business growth?

Many Niko systems use modular, adaptable principles. This means they can support changing layouts, increased capacity or additional operational requirements as a business develops.

Can Folding Door Hardware improve product or asset protection?

Yes. Controlled movement and reliable hardware reduce the risk of accidental impact, mishandling or avoidable wear, helping protect valuable products, buildings and equipment.

Why should a company choose Niko for Folding Door Hardware?

Niko combines long-standing engineering expertise, high-quality manufacturing and practical system design to deliver solutions that improve safety, productivity and long-term reliability.

How do Folding Door Hardware help operators and employers at the same time?

Operators benefit from safer, easier work, while employers benefit from better productivity, reduced risk and more reliable operations. This makes Folding Door Hardware a strong investment for both people and performance.

What is this product also known as?

Folding door track
Folding door rail
Folding door gear
Barn door track
Barn door rail
Barn door gear
Top folding door track
Top folding door rail
Top folding door gear
Industrial folding door track
Industrial folding door rail
Industrial folding door gear
